Z series rock mucking loader machine is a light-duty loading equipment for rail-wheel type underground tunneling and stope. It has compact structure, strong adaptability, reliable work, easy operation and maintenance.
Product Description(Underground Mining Pneumatic Rock Mucking Loader Machine)
Z series rock loader is a light-duty loading equipment for rail-wheel type underground tunneling and stope. It has compact structure, strong adaptability, reliable work, easy operation and maintenance. It can be loaded on general rocks, large stones, iron ore, granite and other metal or non-metal mines, and can load up to 500MM with a slope of 100m~400m, the loading efficiency is the highest, and it is suitable for horizontal roadways in various mines (gradient ≤8). The machine is a bucket type, front loading and rear unloading, self-propelled, and its power source is pneumatic and electric.
Operation video
Shipment and one site details
←No Information
Specification Table
| Model | Z-17AW | Z-20AW | Z-30AW | ZQ-26 | ||
| Loading capacity m3/h | 20-30 | 30-40 | 50-60 | 40-50 | ||
| Loading area m3 | 0.17 | 0-20 | 0.3 | 0.26 | ||
| Loading width m | 1.7 | 2 | 2.2 | 2.7 | ||
| Track gauge mm | 500600762 or 900 | |||||
| Power | Motor | Motor | Motor | Wind motor | ||
| Walking power kw | 10.5 | 10.5 | 15 | 10.5 | ||
| Lifting bucket power KW | 10.5 | 13 | 15 | 15 | ||
| Unloading height mm | 10.5 | 1360 | 1370 | 1250 | ||
| Dimension mm | Length | 2120 | 2480 | 2620 | 2440 | |
| Width | 1011 | 1380 | 1320 | 1380 | ||
| Height | 1920 | 1460 | 1545 | 1500 | ||
| Weight | 3760 | 3700 | 4600 | 2700 | ||
