ZQ-30-2 30kw Dc Traction Motor For Mining Trolley Locomotive

ZQ-30-2 Dc traction motor the power is 30kw and it could be applied in the 10 ton mining trolley locomotive of Secondary transmission

CJY10 Ton Underground Mining Trolley Locomotive

The ZQ-30-2 Dc traction motor adopts totally enclosed self-cooling structure. The shaft is extended at one end the shaft is cylindrical and the locomotive is driven by the two-stage gear transmission through the couplingaxis. The lower part of the motor is fixed with four feet which is a full suspension device.

ZQ-30-2 Mine general DC traction motor is suitable for general mine underground environment conditions and it is for CJ10 / 550 type DC trolley mine electric locomotive as the driving motor

Power 30Kw
Voltage 550V
Current 61A
Rotating speed 1435r/min
Max Current 122A
Max Rotating 3014r/min
Structural type Horizontal
Working rating S2-60MIN
Excitation mode excitation
Insulation grade F or H
Type of cooling IC40
Weight 410KG
