Home > Product > Locomotive Spare Parts > Locomotive Dc Motors
This ZQ-30 DC motors is alppied in 10 ton mining trolley locomotive, with the power of 30KW.
The ZQ-30 DC traction motor is applied as the traction motor of mining trolley locomotive of two-stage driving (twice of speed variation) of Model CJY10-6.7.9/250. Its applicable designs and compact structure make the motor suitable for ordinary underground mining workplace as well as other ground environment.
 |
Motor Power | 30Kw |
| Voltage | 250V | |
| Current | 135A | |
| Rotating speed | 1435r/min | |
| Max Current | 270A | |
| Max Rotating | 3014r/min | |
| Structural type | Horizontal | |
| Working rating | S2-60MIN | |
| Excitation mode | excitation | |
| Insulation grade | F | |
| Type of cooling | IC40 | |
| Weight | 400KG |
Advantages of our Motor
