12 Ton Battery Powered Mine Locomotive

We have specialized in mining locomotive for many years, could offer battery powered mining locomotive with CE certification and factory price.

CJY10 Ton Underground Mining Trolley Locomotive

Maintenance requirements for Battery Powered Mine Locomotive

1.Perform regular deep discharge

2. Keep the battery fully charged.

3. The smaller the discharge depth of the battery each time, the longer the life of the capacitor

4. The charging time should be different according to the mileage. The longer the mileage, the longer the charging time. Otherwise, the charging time is controlled to 4-12 hours, and the charging time should not be long.

5. Use a matching charger when charging. Keep it in a cool and ventilated place to avoid high temperature and humidity. Do not let water enter the charger to prevent electric shock.



Features

  • Heavy duty loading capacity

  • Smoothly climbing and moving

  • Safe braking control system

  • Reliable and easy operation

  • Simple maintenance

  • 25-30% energy saving compared to DC driving type

  • Less emission, Eco-Friendly



Locomotive Avantage Please ClickLocomotive Advantages.

4.Video



Shipment and one site details

8o12t battery locomotive 1.jpg







Model CTY12/679G(B)
Weight 12t
Track gauge 600762 or 900mm
Traction force 16.48kN
Max traction force 29.43kN
Speed 8.7km/h
Battery device voltage 192V
capacity 560Ah
Motor power 22Kw x 230Kw x 2
Dimensions Length 5100mm
width 10501212 or 1350mm
Height 1800mm
Wheel base 1220mm
Wheel diameter Φ680mm
Min turn radius 10m
Controller method Resistance,IGBT or frequency
Brake method Mechnical,Electric,Ac frequency
