5 Ton Electric Mining Flameproof Battery Locomotive

5 Ton Electric Mining Flameproof Battery Locomotive generally refers to the traction equipment for rail transportation, and is the locomotive of rail vehicles. It is powered by a high-voltage cable or battery, and uses an electric motor to provide pow

CJY10 Ton Underground Mining Trolley Locomotive

5 Ton Electric Mining Flameproof Battery Locomotive generally refers to the traction equipment for rail transportation, and is the "locomotive" of rail vehicles. It is powered by a high-voltage cable or battery, and uses an electric motor to provide power to drive the wheels to rotate. Therefore, its traction is not only limited by the power of the traction motor, but also by the friction coefficient between the wheels and the rail surface. In addition, the gradient of the transportation track also has a significant impact on its transportation capacity. Generally, the gradient is required to be 3‰, and the local gradient cannot exceed 30‰.

5 Ton Electric Mining Flameproof Battery Locomotive(图1) Model CTY5/679G(B)
Total-weight 5t
Track gague 500600762 or 900mm
Tracktion force 7.06kN
Max traction 12.26kN
Speed 7km/h
Battery device Voltage 90V
Capacity 385Ah
Motor power 7.5 kW×2
dimensions Lenght 3170mm
Width 9201082 or 1220mm
Height 1550mm
Wheel base 850mm
Wheel diameter Φ520mm
Min turn radius 6m
Controlling way Resistence or IGBT
Brake way Mechnical brake or hydraulic


Shipment and one site details

5t battery locomotive 2.jpg

shipment and site 11.jpg

5t battery locomotive 1.jpg
