Electric Remote Control Rock Loader

1. The orginal two electric control boxes have become one and another place has been replaced with hydraulic device. A set of Hydraulic motors is added between turntable and tray driving turntable rotating.2. Via a set of remote controller the machi

Send Inquiry →
CJY10 Ton Underground Mining Trolley Locomotive
Structure of Remote Control Rock Loader
1. The orginal two electric control boxes have become one and another place has been replaced with hydraulic device. A set of Hydraulic motors is added between turntable and tray driving turntable rotating.
2. Via a set of remote controller the machine can be remote-controlled operation.

Featurs of Remote Control Rock Loader
1. Long distance(between 5m-20m) keeps operators from dangers.
2.Opereator are relived from tedious labor with the enhancement of working enviroment.
3.Efficiency is enhanced by above 30% as for its visual operation.
4.Lighting device is added in head of the machine with three modes : remote control button control back up control.

Operation Video


Hot Tags:

←Z-17 Electric Rock Mucking Machine

Pneumatic Rock Loader Machine→

Related Product
Specification
Model Z-17AW Z-20AW Z-30AW ZQ-26
Loading capacity m³/h 20-30 30-40 50-60 40-50
Loading area m³ 0.17 0-20 0.3 0.26
Loading width m 1.7 2 2.2 2.7
Track gauge mm 500600762 or 900
Power Motor Motor Motor Wind motor
Walking power kw 10.5 10.5 15 10.5
Lifting bucket power KW 10.5 13 15 15
Unloading height mm 10.5 1360 1370 1250
Dimension mm Length  2120 2480 2620 2440
Width 1011 1380 1320 1380
Height 1920 1460 1545 1500
Weight 3760 3700 4600 2700
