Pneumatic rock loader is a orbital loader with single bucket directly unloaded its main use is loading the rocks and ore blasting down the breakout into the mine car loading rock coal limestone or sand etc in the open air also.
Pneumatic rock loader fbr rail gauge 600 mm height at 2.25 meters above the roadway roadway width of 1.8-2.5 m slope less than 8 ° of the horizontal roadway work .
The packaging material a very wide and can load a variety of hard rock and ore the maximum size of rock can be installed up to 500 mm 200-300 mm in size rocks within the best efficiency.
Pneumatic rock loader structure is compact convenient and reliable operation good sealing dust-proof moisture resistant.
It can working in a gas and flammable gas environment because of the use of compressed air power source.
| Model | Z-17AW | Z-20AW | Z-30AW | ZQ-26 | ||
| Loading capacity m³/h | 20-30 | 30-40 | 50-60 | 40-50 | ||
| Loading area m³ | 0.17 | 0-20 | 0.3 | 0.26 | ||
| Loading width m | 1.7 | 2 | 2.2 | 2.7 | ||
| Track gauge mm | 500600762 or 900 | |||||
| Power | Motor | Motor | Motor | Wind motor | ||
| Walking power kw | 10.5 | 10.5 | 15 | 10.5 | ||
| Lifting bucket power KW | 10.5 | 13 | 15 | 15 | ||
| Unloading height mm | 10.5 | 1360 | 1370 | 1250 | ||
| Dimension mm | Length | 2120 | 2480 | 2620 | 2440 | |
| Width | 1011 | 1380 | 1320 | 1380 | ||
| Height | 1920 | 1460 | 1545 | 1500 | ||
| Weight | 3760 | 3700 | 4600 |
2700 |
||
