The 10 ton trolley locomotive has 2 type voltage one is 250V and the other is 550V. The traction of pull is about 100 ton ores.
Product introduction
The 10 ton trolley locomotive has four options: normal type thicken lateral plate type added sails type and two- motors type.
The working rated voltages include 250V and 550V. It could pull about 100 ton ores. It has the advantages of short wheel base
and forceful traction. Suitable for middle or big mines as a main transporation vehicle.
Factory Video
Why choose us?
←No Information
|
10ton Trolley Locomotive |
|||
|
Model |
CJY10/6、7、9G(B)(P) |
||
|
Adhesive / total weight |
10t |
||
|
Track gauge |
600、762 or 900mm |
||
|
Traction |
13.05kN |
18.93kN |
|
|
Max. Traction |
24.5kN |
||
|
Speed |
11km/h |
||
|
Direct Voltage |
250V |
550V |
|
|
motor power |
24Kw×2 |
30kW×2 |
|
|
Dimensions |
Length |
4550mm |
|
|
Width |
1050、1212 or 1350mm |
||
|
Height |
1600mm |
||
|
Wheel base |
1100、1220mm |
||
|
Wheel Diameter |
Φ680mm |
||
|
Operational height of current-controller |
1800~2200mm、2000~2400mm |
||
|
Min Curve radius |
7、10m |
||
|
Controller |
Resistance or IGBT |
||
|
Braking method |
Mechanical Brake |
||
