3.5 Ton Trolley Locomotive is specilized design for our Albania Clients. Product Features lGreattractiveeffort lHeavydutyloadingcapacity lSmoothlyclimbingandmoving lSafebrakingcontrolsystem lReliableandeasyoperation lSimplemaintenance l25-30%energysav
Product Features
l Great tractive effort
l Heavy duty loading capacity
l Smoothly climbing and moving
l Safe braking control system
l Reliable and easy operation
l Simple maintenance
l 25-30% energy saving compared to DC driving type
l Less emission, Eco-Friendly
Parameters
| Model No.CJY3/6,7,9G(B) | ||
| Adhesive / Total weight (t) | 3 | |
| Track gauge (mm) | 600,762 or 900 | |
| Traction (KN) | 6.1KN/5.14KN | |
| Max. Traction (KN) | 7.36KN | |
| Speed(Km/h) | 10.6km/h/7.5km/h | |
| DC Voltage (V) | 250V/550V | |
| Power (KW) | 12kw*1/6.5kw*2 | |
| Dimensions | Length(mm) | 2700mm/2750mm |
| Width(mm) | 940,1082 or 1220 | |
| Height(mm) | 1550 | |
| Wheelbase (mm) | 816mm/850mm | |
| Wheel diameter (mm) | Φ650mm/Φ520mm | |
| Min Curve radius (m) | 5.7m/6m | |
| Controller | Resistance or IGBT | |
| Braking method |
Mechanical Brake |
|
