12 Ton Explosion-proof Locomotive

Our factory could customized flameproof locomotive with competitive price. Covering the market in South America and Europe. Hope we can start business cooperation with you.

CJY10 Ton Underground Mining Trolley Locomotive

Product Description

Adopting advanced fast braking device the brake is fast and reliable. The car body is highly resistant to impact. The speed regulation has protection functions such as short circuit phase loss over-voltage and under-voltage of the motor. The 12-ton battery electric locomotive is equipped with an on-board battery capacity indicator to monitor the remaining capacity of the battery and prevent it from stopping without power on the way.



Explosion-proof Locomotive is a kind of driven the vehicle with proof performance for containing flammable gas and coal dust and other dangerous places traction transport of mining locomotives traction battery and then following the hydraulic transmission of a utility model traction. Mine explosion-proof drum & rail locomotive diesel engine series is in line with the ideal of coal mine production safety transportation equipment.



A locomotive contains 2 sets of batteries a charger the net weight of the loadable minerals is 8-10 tons and the motor and battery are guaranteed for one year. Free replacement or repair if there are quality problems.

Locomotive Avantage Please Click: Locomotive Advantages.

Operation Video



Shipment and one site details

8o12t battery locomotive 1.jpg









12ton Battery Locomotive

Specifications

Adhesive / total weight (t)

12

Track gauge (mm)

600762 or 900

Traction (KN)

16.48

Max. Traction (KN)

29.43

Speed(km/h)

8.7

Max. Speed(km/h)

17.4

Battery Voltage (V)

192

Battery Capacity (Ah)

560

Power (KW)

22*2

Dimensions

Length(mm)

4530

Width(mm)

105012121350

Height(mm)

1600

Coupler height(mm)

320/430

Wheelbase (mm)

1220

Wheel diameter (mm)

680

Min Curve radius (m)

10

Controller

Resistance

Braking method

Mechanical Brake
Electrical Brake or Air Brake
