8 Ton Explosion-proof Locomotive

This 8 ton anti-explosion battery locomotive have several type voltage, 110V,132V and 140V. The more higher voltage, the more endurance.

CJY10 Ton Underground Mining Trolley Locomotive

The 8 ton anti-explosion electric locomotive adopts modular design and stepless speed regulation. The control part is provided with multiple protections, which improves the safety factor when the locomotive is running.

The 8-ton explosion-proof special electric locomotive is a traction device for coal mine rail vehicle transportation, and is suitable for transporting minerals, auxiliary materials, equipment and personnel in underground.

Locomotive Avantage Please Click: Locomotive Advantages.

Operation video



Shipment and one site details

8o12t battery locomotive 1.jpg







Technical Specification


Model CTY(L)8/679G
Dead-weight 8t
Track gague 600762 or 900mm
Tracktion force 11.18kN 12.83kN
Speed 6.2km/h 7.5 km/h 7.8 km/h
Max traction 19.62kN
Battery device Voltage 110V 132V 140V 144V
Capacity 440Ah
Motor power 11kW×2 15kW×2
dimensions Lenght 4430mm 4250mm
Width 105012121350mm
Height 1600mm 1600mm
Wheel base 1100mm 1150mm
Wheel diameter Φ680mm Φ680mm Φ600mm
Min turn radius 7m
Controlling way Resistence or IGBT or AC Converter
Brake way Mechnical brake or air brake

8 Ton Explosion-proof Locomotive(图2)
8 Ton Explosion-proof Locomotive(图3)
