The motor is applied as the driving motor of explosion-proof battery locomotive of Model CTY5-6.7.9/90 and suitable for working in workplace with methane and coal dust explosive mixture. As a substitute of DC traction motor this model is designed wi
YBVF-8Q AC Motor is applied as the driving motor of explosion-proof battery locomotive of Model CTY5-6.7.9/90 and suitable for working in workplace with methane and coal dust explosive mixture.
As a substitute of DC traction motor this model is designed with applicable technique and has features of simple and compact structure energy conservation maintenance-free and smooth operation capability.
Specification
| Model | YBVF-8Q |
| Working rating | S2-60min | |
| Power kw | 7.5 | |
| Voltage v | 64 | |
| Current A | 85.7 | |
| Frequency Hz | 38.6 | |
| Speed of rotation r/min | 1128 | |
| Insulation grade | F or H | |
| Level of protection | Ip54 | |
| Weight kg | 170 |
