YVF75Q AC Motor is used on China 20 ton trolley electric locomotive the model type is CJY14/679GP. It has features of simple structure energy conservation maintenance-free smooth operation capability and high efficiency.
YVF75Q (380/220) Mining locomotive general type AC traction motor
This Motor is applied in the 20 ton electric locomotive the power is 75kw.
Long-term storage of the motor should be dismantled and inspected and anti-rust oil should be applied to the necessary parts and then assembled and stored and regularly checked.
Specification
| Model | YVF-75Q |
| Working rating | S2-60min | |
| Power kw | 75 | |
| Voltage v | 400 | |
| Current A | 132 | |
| Frequency Hz | 51 | |
| Speed of rotation r/min | 1001 | |
| Insulation grade | F or H | |
| Level of protection | Ip54 | |
| Weight kg | 530 |
