YVF30Q AC Motor For 10 Ton Trolley Electric Locomotive

YVF30Q AC Motor is used on China 10 ton trolley electric locomotive the model type is CJY10/679GP

CJY10 Ton Underground Mining Trolley Locomotive

YVF30Q AC Motor is used on China 10 ton trolley electric locomotive the model type is CJY10/679GP.

This motor have 2 different outline when make the purchase please confirm with the sales.

When ordering please specify the motor model and specification (power voltage current speed etc.) or matching requirements.

When ordering the special requirements of the user (such as going abroad increasing the quantity of spare goods or packing and transporting separately) shall be indicated in the contract.


motors 1.jpg

motors 2.jpg

motors 3.jpg

motors 4.jpg

motors 5.jpg

motors 6.jpg

motors 7.jpg

shipment and site 18.jpg



Hot Tags: traction motor  |   AC motor  |   mining locomotive  |   battery locomotive  |   trolley locomotive  |

Technical Parameters

Model YVF-30Q YVF30-2
Working rating S2-60min S2-60min
Power kw 30 30
Voltage v 380 380
Current A 60.3 57.8
Frequency Hz 40.1 50
Speed of rotation r/min 595 1479
Insulation grade F or H F or H
Level of protection Ip54 Ip54
Weight kg 490 350
