2.5 Ton Electric Mining Trolley Locomotive

Our factory provide underground mining trolley locomotive with competitive price and excellent services. We have more than 20 years experience of production and maintenance locomotive, covering the market of South America and Africa. Hoping to coopera

CJY10 Ton Underground Mining Trolley Locomotive

2.5 Ton Electric Mining Trolley Locomotive

Product Description

Locomotive is AC-DC transmission diesel locomotive which can undertake passenger and freight traction transport on trunk lines, secondary trunk lines in mountain areas and railways in extremely cold areas.
The locomotive is divided into three types:
1. mountain type double heading passenger and freight diesel locomotive;
2. cold-proof type double heading passenger and freight diesel locomotive;
3. standard type double-cab passenger and freight diesel locomotive.



Product Name: 2.5 ton electric mining trolley locomotive

Fuel Type: Electric

Brand Name: HNYT

Traction mode power: 12x1

Dimensions (L x W x H) (mm): 2700*940*1550mm

Speed (km/h): 10.6km/h

Application: Mining; Subway ,Tunnel Locomotive

Rail gauge: 600/762/900mm

Place of Origin: Xiangtan, China (Mainland)

Rated voltage: 550V

Advantages: Strong traction force

Braking type: Mechanical and Electric

Service: OEM/ODM

Speed control: Resistor or AC or IGBT



The working process of Electric Mining Trolley Locomotive

After the high-voltage alternating current is reduced and rectified by the traction converter, the positive electrode is connected to the overhead line, and the negative electrode is connected to the rail. The pantograph on the locomotive is in contact with the overhead line to introduce current into the vehicle, and then enters the traction motor through the automatic air switch, controller, and resistance box to drive the motor. The electric motor drives the wheels to rotate through the transmission device, thereby pulling the train to travel. The current flowing from the motor flows back to the substation through the track.




Shipment and one site details

3t trolley locomotive 2.jpg
